FLANGE PN10 76.1 SB 1.4404 E

FLANGE PN10 76.1 SB 1.4404 E - ISO EN 10357-D WxW FLANGE COMPLETE WITH 4xM8 EPDM
Manufacturer:
Alfa Laval
In stock:
The green marker indicates that the product is typically in stock. The yellow marker indicates that the product typically has a little longer lead time
Product code:
5058
HS Code:
73072980
Item number:
9612498714
Delivery time:
1-3 days
  • Range: Flanges
  • Product Model: ISO EN 10357-D Pressure Flanges
  • Size: 76.1 mm
  • Material: 1.4404/EPDM
  • Finish: SB (ID=0.8/OD=1.0)
  • Connection Type: Weld ends
  • Standard: ISO 2037
  • Design: Complete
  • Item Weight: 1.89
Price:
Login to view price
A: 132.00
B: 50.00
C: 4.00 x M8
OD/ID x t: 76.10/72.90 x 1.60
Pressure class PN (Bar): 10
