B7RWWW-2 X 1-316L-PM

B7RWWW-2 X 1-316L-PM - BPE WELD RED T 15RAEP/POL SF4
Manufacturer:
Alfa Laval
In stock:
The green marker indicates that the product is typically in stock. The yellow marker indicates that the product typically has a little longer lead time
Product code:
5036
HS Code:
7307230090
Item number:
9634001072
Delivery time:
1-3 days
  • Range: Tees
  • Product Model: Tri-Clover BPE Reducing Tees
  • Size: 2"
  • Second Size: 1"
  • Material: 316L
  • Finish: SF4(PM) (ID=15EP/OD=32µin)
  • Connection Type: Weld ends
  • Standard: ASME BPE
  • Design: B7RWWW
  • Item Weight: 0.37
Price:
Login to view price
A: 73.00
B: 66.70
OD/ID x t: 50.80/47.50 x 1.65
OD1/ID1 x t1: 50.80/47.50 x 1.65
OD2/ID2 x t2: 25.40/22.10 x 1.65
